Polecat Wall Fixing Kit Install

Units come complete with an installation pack that contains the following:

1 Foot
2 Connecting Pins
2 Foam Pads (plus spare)
1 Fixing Block
2 Fixing Screws
2 Fixing Plugs
1 Drill Bit

It’s easier if you have an extra pair of hands to install your Hicat® & you'll need a step ladder, medium size cross headed screwdriver, tape measure, pencil & a drill - if you have a stud/joist sensor this will also be useful & if fixing into masonry you may need a specialist drill bit



Polecat Wall Fixing Kit Install 1


1  Install the two connecting pins into the two outer inserts on top of the Hicat® & the foot into the middle insert on the base - if you are installing the unit on a smooth hard floor stick the foam pad on to the foot


Polecat Wall Fixing Kit Install 2


2  Remove cat



Polecat Wall Fixing Kit Install 3


3  Use the connecting pins to attach the fixing block on to the top of the Hicat® - make sure you push the connecting pins into the block until they click into position noting that the seam should be at the back of the unit when installed



Polecat Wall Fixing Kit Install 4


4  The supplied Fixing Plugs are universal & suitable for fixing into plasterboard, timber or masonry - installing into plasterboard will give a secure fixing & you can also secure through plasterboard into a stud or joist



Polecat Wall Fixing Kit Install 5


5  Remove cat



Polecat Wall Fixing Kit Install 6


6  Move the Hicat® into its proposed position making sure the foot on the unit has been adjusted to its installed height - a 20mm space at the bottom of the Hicat® is recommended



Polecat Wall Fixing Kit Install 7


7  Mark-up along the top edge of the fixing block then unscrew the fixing plate & use this as a guide to mark-up the fixing holes on the wall



Polecat Wall Fixing Kit Install 8


8  Drill the fixing holes making sure they are at least 60mm deep into the wall & then install the fixing plugs into the holes



Polecat Wall Fixing Kit Install 9


9  Screw the fixing plate on to the wall with the fixing block face-up then re-attach the fixing block to the mounting plate with the Hicat® attached



Polecat Wall Fixing Kit Install 10


10  Remove cat



Polecat Wall Fixing Kit Install 11


11  Make sure the Hicat® is plumb & that the fixing block, fixing plate & connectors are all secure before allowing your cat to play on the unit



Polecat Wall Fixing Kit Install 12


12  Give your Hicat® a good vacuum to remove any loose fibres & once in use check from time to time that the fixing block is secure, the connectors are engaged & the unit is stable - you may also need to adjust the foot slightly to level out the Hicat® over time



Polecat Wall Fixing Kit Install 13


13  f the base of your Hicat® moves on hard flooring during boisterous play remove the foam pad from the foot & fix the spare foam pad to the floor directly under the foot



Polecat Wall Fixing Kit Install 14


14  Playtime
